D=65-300mm

Q=50-1800m3/h

H=50-94m

a) Caliber: DN65-DN300mm
b) Flow:50-1800m3/hr
c) Head:50-94 m
d) Rotate speed:740-2900r/min
e)Working pressure: ≤3.6mpa

ZGB Slurry Pump Function Introduction

1. The structure of ZGB(P) pump is horizontal, single-suction, single-stage, cantilever, double-casing and centrifugal, and the wet parts of the same discharge between ZGB and ZGBP can be interchanged;

2. Designed with CAD software, good hydraulic performance, high efficiency and lower abrasion;

3. Wider flow channel, good ability of non-clogging and NPSH;

4. Expeller seal combined with packing seal and mechanical seal to guarantee that no leakage will happen;

5. Reliable design ensures the MTBF (Mean Time between Failures) can be increased significantly;

6. Bearing is lubricated with thin oil, and it can work under low temperature by setting the lubrication and cooling system reasonable;

7. Wet parts are made of special material with good ability of corrosion and wear;

8. The pumps can be connected in multi-stage in series under the allow pressure (3.6MPa).

ZGB series Pump Typical Application

Delivery of slurry with strong abrasion and high concentration for various of industry conditions, especially high head conditions

• Chemical Process

• Heavy Minerals

• Paper and Pulp

• Mill Discharge

• Sugar Beet

• Slag Granulation

• Bottom Boiler and Fly Ash

• Cyclone Feed

• Power Plants

• other industry
